Temperature Micro Logger 1430 Smart indicator series
Intelligent temperature logger for
refrigeration
Wireless data communication
Over 14,000 data readings stored
Non-volatile memory
Industry standard Thermistor supplied
Configurable data log interval
Monitors mains power interruptions
100 to 230Vac ±20% 50/60Hz.
Less than 1 watt (power consumption)
UL Recognised. File no. E311309
CE Mark
FCC compliant
Programmable upper/lower limit alarm
Blue LED indicates normal operation
Red LED indicates problem
Snap-in mounting
Panel cut out:
30.0 x 11.0
C 1435 A L - - -
TERMINAL FUNCTION SOFTLINE LENS BODY COLOUR
RoHS
RoHS compliant
TERMINAL
BODY & DIMENSIONS
SPECIFICATION
C
L Panel Cut-Out
Dimensions
Bezel 32.0mm x 14.0mm
Panel cut-out 11.0/11.1mm x 30.0/30.1mm
Panel thickness
0.75mm to 2.5mm
6.3 x 0.8
30.0
30.1
Body
Lens
Terminals
Nylon 6.6, matt finish, black colour is standard
Clear Polycarbonate, Softline matt finish
Copper alloy, Silver plated
H
11.0/11.1
Flame retardancy
RoHS compliant
UL94V-0
Yes
Bezel
Operating supply
Power consumption
100 to 230Vac ±20% 50/60Hz.
Less than 1 Watt
T
4.8 x 0.8
R1.0
14.0
32.0
Operating conditions (body)
Measurement range
Measurement accuracy
–20°C to +70°C (–4°F to 158°F)
0 to 95% RH (non-condensing)
–30oC to +80oC (–22oF to +176oF)
±1.0oC (±1.8F)
Measurement resolution
±0.5oC (±0.9oF)
?2.1
Solder
Dimensions
Temperature sensor
Communications method
NTC Thermistor, sealed sensor, cable length 1m
Infrared serial data port
X
66
Logging Interval
Logging data capacity
Data retention
Programmable 1 second to 12 hours per reading
>14,000 measurements stored
>10 years without power
4.0
PCB 0.8Sq
Electromagnetic Compatibility
EMC Immunity
EMC Emissions
Approvals
Compliant with directives 89/336/EEC & 92/31/EEC
EN 55014-2:1997 Household appliances
EN 61000-6-2:2005 Industrial Environments,10 V/m
EN 61000-4-2:1995 Electrostatic Discharges (ESD)
EN 61000-4-3:2002 RF Electromagnetic fields
EN 61000-4-4:2004 Fast Transients & Bursts
EN 61000-4-5:1995 Surges
EN 61000-4-6:1996 Conducted disturbances
EN 61000-4-11:2004 Voltage dips & interruptions
EN 55014-1:2001 Household appliances
EN 55022 Class B:1998 Domestic environments
UL Recognised
FCC compliant
CE Mark
All dimensions in millimetres (mm)
Standards
UL 508
CSA C22.2 No. 14-05
98
tel: +44 (0)20 8979 3232 ? Arcolectric ? email: info@arcoswitch.co.uk
